• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Datum Diameter (B)	13.6
Datum Diameter (A)	13.2
Material	Cast Iron
Overall Length (in)	4.171875 in
Pulley Material	Cast Iron
Bushing Used	R1
Outside Diameter (in)	13.95 in
Number of Grooves	5
Pitch Diameter (A)	13.4
Pitch Diameter (B)	13.9
Belt Section	A, B
Product Type	Multiple Sheaves
Bore (Min) (in)	1.125 in
Bore Type	Split Taper Bushed
Face Width (in)	4
Keyway Size	.750
Bushing Bore Range	1.125 - 3.750
Overall Width (in)	4.15625
Pulley Construction	Spoked

General Specifications

UPC	662289310944
Weight	42.48 LB
Packaged Length	14.90 IN
Packaged Width	14.90 IN
Packaged Height	4.10 IN
