• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Datum Diameter (A)	10.6
Number of Grooves	5
Pitch Diameter (A)	10.8
Material	Cast Iron
Datum Diameter (B)	11
Model Name	5AB_LG_Sheavemaster
Bushing Used	SF
Outside Diameter (in)	11.35 in
Pulley Material	Cast Iron
Pitch Diameter (B)	11.3
Bore (Min) (in)	0.5 in
Product Type	Multiple Sheaves
Belt Section	A, B
Bore Type	QD Bushed
Bushing Bore Range	0.500 - 2.938

General Specifications

UPC	662289336586
Weight	32.40 LB
Packaged Length	11.38 IN
Packaged Width	11.38 IN
Packaged Height	4.00 IN
