• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Datum Diameter (B)	11
Overall Length (in)	4.171875 in
Pitch Diameter (A)	10.8
Pulley Material	Cast Iron
Number of Grooves	5
Material	Cast Iron
Outside Diameter (in)	11.35 in
Pitch Diameter (B)	11.3
Datum Diameter (A)	10.6
Bushing Used	R1
Belt Section	A, B
Bore (Min) (in)	1.125 in
Product Type	Multiple Sheaves
Bore Type	Split Taper Bushed
Keyway Size	.750
Bushing Bore Range	1.125 - 3.750
Face Width (in)	4
Overall Width (in)	4.15625
Pulley Construction	Spoked

General Specifications

UPC	662289154937
Weight	33.40 LB
Packaged Length	11.38 IN
Packaged Width	11.38 IN
Packaged Height	4.00 IN
HTC	8483.50.9040
Country of Origin	Mexico
