• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Pulley Material	Cast Iron
Model Name	53V_LG_Sheavemaster
Pitch Diameter (3V)	6.45
Bushing Used	SK
Material	Cast Iron
Number of Grooves	5
Outside Diameter (in)	6.5 in
Bore (Min) (in)	0.5 in
Product Type	Multiple Sheaves
Belt Section	3V
Number of Hubs	1
Bore Type	QD Bushed
Bushing Bore Range	.500 - 2.625
Face Width (in)	2.3125
Overall Width (in)	2.62
Pulley Construction	Web

General Specifications

UPC	662289383009
Weight	11.34 LB
Packaged Length	7.30 IN
Packaged Width	7.10 IN
Packaged Height	2.80 IN
