• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Pitch Diameter (3V)	5.95
Bushing Used	SK
Model Name	53V_LG_Sheavemaster
Pulley Material	Cast Iron
Number of Grooves	5
Material	Cast Iron
Outside Diameter (in)	6 in
Belt Section	3V
Bore (Min) (in)	0.5 in
Product Type	Multiple Sheaves
Bore Type	QD Bushed
Overall Width (in)	2.3125
Bushing Bore Range	0.500 - 2.625
Pulley Construction	Plain
Face Width (in)	2.3125

General Specifications

UPC	662289323258
Weight	9.21 LB
Packaged Length	6.20 IN
Packaged Width	6.30 IN
Packaged Height	2.50 IN
