• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Number of Grooves	4
Overall Length (in)	4.578125 in
Pitch Diameter (C)	9.8
Bushing Used	Q2
Datum Diameter (C)	9.4
Material	Cast Iron
Model Name	4TC-L_Sheave_Master
Outside Diameter (in)	9.8 in
Pulley Material	Cast Iron
Belt Section	C
Bore (Min) (in)	1 in
Product Type	Multiple Sheaves
Bore Type	Split Taper Bushed
Number of Hubs	1
Face Width (in)	4.25
Bushing Bore Range	1.000 - 2.625
Overall Width (in)	4.53125
Keyway Size	0.5
Pulley Construction	Spoke

General Specifications

UPC	662289113385
Weight	32.44 LB
Packaged Length	10.06 IN
Packaged Width	10.06 IN
Packaged Height	4.25 IN
