• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Material	Cast Iron
Datum Diameter (C)	8.6
Pulley Material	Cast Iron
Number of Grooves	4
Model Name	4TC-L_Sheave_Master
Pitch Diameter (C)	9
Bushing Used	Q2
Overall Length (in)	4.578125 in
Outside Diameter (in)	9 in
Belt Section	C
Bore (Min) (in)	1 in
Product Type	Multiple Sheaves
Bore Type	Split Taper Bushed
Keyway Size	.500
Overall Width (in)	4.53125
Pulley Construction	Webbed
Face Width (in)	4.25
Bushing Bore Range	1.000 - 2.625

General Specifications

UPC	662289243181
Weight	27.65 LB
Packaged Length	9.06 IN
Packaged Width	9.06 IN
Packaged Height	4.75 IN
