• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Datum Diameter (C)	8
Pitch Diameter (C)	8.4
Bushing Used	Q2
Pulley Material	Cast Iron
Outside Diameter (in)	8.4 in
Model Name	4TC-L_Sheave_Master
Number of Grooves	4
Overall Length (in)	4.578125 in
Material	Cast Iron
Belt Section	C
Bore (Min) (in)	1 in
Product Type	Multiple Sheaves
Bore Type	Split Taper Bushed
Pulley Construction	Webbed
Overall Width (in)	4.53125
Keyway Size	.500
Bushing Bore Range	1.000 - 2.625
Face Width (in)	4.25

General Specifications

UPC	662289163076
Weight	29.27 LB
Packaged Length	9.10 IN
Packaged Width	9.10 IN
Packaged Height	5.60 IN
