• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Material	Cast Iron
Datum Diameter (C)	7.2
Pitch Diameter (C)	7.6
Bushing Used	Q2
Model Name	4TC-S_Sheave_Master
Pulley Material	Cast Iron
Outside Diameter (in)	7.6 in
Number of Grooves	4
Overall Length (in)	4.578125 in
Bore (Min) (in)	1 in
Belt Section	C
Product Type	Multiple Sheaves
Bore Type	Split Taper Bushed
Bushing Bore Range	1.000 - 2.625
Keyway Size	.500
Pulley Construction	Webbed
Overall Width (in)	4.53125
Face Width (in)	4.25

General Specifications

UPC	662289142804
Weight	25.78 LB
Packaged Length	9.10 IN
Packaged Width	9.00 IN
Packaged Height	4.50 IN
