• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Datum Diameter (C)	10.2
Model Name	4TC-L_Sheave_Master
Overall Length (in)	4.578125 in
Outside Diameter (in)	10.6 in
Bushing Used	Q2
Number of Grooves	4
Material	Cast Iron
Pulley Material	Cast Iron
Pitch Diameter (C)	10.6
Belt Section	C
Product Type	Multiple Sheaves
Bore (Min) (in)	1 in
Bore Type	Split Taper Bushed
Bushing Bore Range	1.000 - 2.625
Keyway Size	.500

General Specifications

UPC	662289193523
Weight	36.81 LB
Packaged Length	11.06 IN
Packaged Width	11.06 IN
Packaged Height	4.25 IN
HTC	8483.50.9040
Country of Origin	Mexico
