• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Pitch Diameter (B)	7.1
Pitch Diameter (A)	6.6
Datum Diameter (B)	6.8
Model Name	4TB-L_Sheave_Master
Outside Diameter (in)	7.15 in
Datum Diameter (A)	6.4
Material	Cast Iron
Pulley Material	Cast Iron
Overall Length (in)	3.453125 in
Bushing Used	P1
Number of Grooves	4
Product Type	Multiple Sheaves
Belt Section	A, B
Bore (Min) (in)	0.5 in
Bore Type	Split Taper Bushed
Keyway Size	.375
Bushing Bore Range	0.500 - 1.750
Overall Width (in)	3.5
Pulley Construction	Webbed
Face Width (in)	3.25

General Specifications

UPC	662289111893
Weight	13.10 LB
Packaged Length	7.19 IN
Packaged Width	7.19 IN
Packaged Height	3.25 IN
HTC	8483.50.9040
Country of Origin	Mexico
