• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Datum Diameter (B)	5.6
Bushing Used	P1
Pitch Diameter (B)	5.9
Pulley Material	Cast Iron
Datum Diameter (A)	5.2
Outside Diameter (in)	5.95 in
Overall Length (in)	3.453125 in
Number of Grooves	4
Pitch Diameter (A)	5.4
Model Name	4TB-L_Sheave_Master
Material	Cast Iron
Bore (Min) (in)	0.5 in
Belt Section	A, B
Product Type	Multiple Sheaves
Bore Type	Split Taper Bushed
Keyway Size	.375
Pulley Construction	Webbed
Face Width (in)	3.25
Overall Width (in)	3.5
Bushing Bore Range	0.500 - 1.750

General Specifications

UPC	662289271566
Weight	11.25 LB
Packaged Length	6.06 IN
Packaged Width	6.06 IN
Packaged Height	3.25 IN
