• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Pitch Diameter (5V)	9.65
Pulley Material	Cast Iron
Overall Length (in)	3.703125 in
Outside Diameter (in)	9.75 in
Number of Grooves	4
Bushing Used	R1
Material	Cast Iron
Belt Section	5V
Bore (Min) (in)	1.125 in
Product Type	Multiple Sheaves
Bore Type	Split Taper Bushed
Bushing Bore Range	1.125 - 3.750
Pulley Construction	Webbed
Face Width (in)	3.0625
Overall Width (in)	3.6875
Keyway Size	.750

General Specifications

UPC	662289230761
Weight	28.26 LB
Packaged Length	10.30 IN
Packaged Width	10.30 IN
Packaged Height	3.60 IN
