• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Number of Grooves	4
Pitch Diameter (5V)	7.9
Overall Length (in)	3.703125 in
Material	Cast Iron
Bushing Used	R1
Pulley Material	Cast Iron
Outside Diameter (in)	8 in
Belt Section	5V
Product Type	Multiple Sheaves
Bore (Min) (in)	1.125 in
Bore Type	Split Taper Bushed
Bushing Bore Range	1.125 - 3.750
Face Width (in)	3.0625
Pulley Construction	Webbed
Keyway Size	.750
Overall Width (in)	3.6875

General Specifications

UPC	662289200504
Weight	19.65 LB
Packaged Length	8.50 IN
Packaged Width	8.50 IN
Packaged Height	3.25 IN
