• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Pulley Material	Cast Iron
Outside Diameter (in)	13.2 in
Material	Cast Iron
Bushing Used	R1
Pitch Diameter (5V)	13.1
Number of Grooves	4
Overall Length (in)	3.703125 in
Bore (Min) (in)	1.125 in
Product Type	Multiple Sheaves
Belt Section	5V
Bore Type	Split Taper Bushed
Number of Hubs	1
Keyway Size	0.75
Pulley Construction	Spoke
Bushing Bore Range	1.125 - 3.750
Face Width (in)	3.0625
Overall Width (in)	3.6875

General Specifications

UPC	662289191116
Weight	35.05 LB
Packaged Length	14.00 IN
Packaged Width	14.00 IN
Packaged Height	3.25 IN
