• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Overall Length (in)	3.703125 in
Pitch Diameter (5V)	12.4
Bushing Used	R1
Pulley Material	Cast Iron
Outside Diameter (in)	12.5 in
Number of Grooves	4
Material	Cast Iron
Belt Section	5V
Bore (Min) (in)	1.125 in
Product Type	Multiple Sheaves
Bore Type	Split Taper Bushed
Face Width (in)	3.0625
Pulley Construction	Webbed
Bushing Bore Range	1.125 - 3.750
Overall Width (in)	3.6875
Keyway Size	.750

General Specifications

UPC	662289141074
Weight	37.33 LB
Packaged Length	13.30 IN
Packaged Width	13.40 IN
Packaged Height	3.30 IN
