• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Number of Grooves	4
Outside Diameter (in)	10.9 in
Pulley Material	Cast Iron
Bushing Used	R1
Pitch Diameter (5V)	10.8
Overall Length (in)	3.703125 in
Material	Cast Iron
Belt Section	5V
Product Type	Multiple Sheaves
Bore (Min) (in)	1.125 in
Bore Type	Split Taper Bushed
Number of Hubs	1
Overall Width (in)	3.6875
Pulley Construction	Web
Keyway Size	0.75
Bushing Bore Range	1.125 - 3.750
Face Width (in)	3.0625

General Specifications

UPC	662289190898
Weight	33.29 LB
Packaged Length	11.70 IN
Packaged Width	11.60 IN
Packaged Height	3.40 IN
