• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Pulley Material	Cast Iron
Number of Grooves	4
Overall Length (in)	3.171875 in
Material	Cast Iron
Bushing Used	R1
Pitch Diameter (3V)	18.95
Outside Diameter (in)	19 in
Bore (Min) (in)	1.125 in
Product Type	Multiple Sheaves
Belt Section	3V
Bore Type	Split Taper Bushed
Bushing Bore Range	1.125 - 3.750
Keyway Size	.750
Overall Width (in)	3.15625
Pulley Construction	Spoked
Face Width (in)	1.9063

General Specifications

UPC	662289311965
Weight	35.56 LB
Packaged Length	19.75 IN
Packaged Width	19.75 IN
Packaged Height	2.00 IN
