• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Pulley Material	Cast Iron
Bushing Used	Q1
Number of Grooves	4
Pitch Diameter (3V)	6.45
Overall Length (in)	2.90625 in
Material	Cast Iron
Outside Diameter (in)	6.5 in
Belt Section	3V
Product Type	Multiple Sheaves
Bore (Min) (in)	0.75 in
Bore Type	Split Taper Bushed
Keyway Size	.500
Face Width (in)	1.9063
Bushing Bore Range	2.6875 - 2.6875
Pulley Construction	Webbed
Overall Width (in)	2.859375

General Specifications

UPC	662289129942
Weight	11.13 LB
Packaged Length	6.70 IN
Packaged Width	6.70 IN
Packaged Height	2.30 IN
