• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Outside Diameter (in)	6 in
Pulley Material	Cast Iron
Number of Grooves	4
Bushing Used	Q1
Overall Length (in)	2.828125 in
Material	Cast Iron
Pitch Diameter (3V)	5.95
Belt Section	3V
Product Type	Multiple Sheaves
Bore (Min) (in)	0.75 in
Bore Type	Split Taper Bushed
Pulley Construction	Plain
Overall Width (in)	2.78125
Bushing Bore Range	2.6875 - 2.6875
Face Width (in)	1.9063
Keyway Size	.500

General Specifications

UPC	662289269808
Weight	8.97 LB
Packaged Length	6.80 IN
Packaged Width	6.80 IN
Packaged Height	2.30 IN
