• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Overall Length (in)	2.90625 in
Bushing Used	Q1
Number of Grooves	4
Outside Diameter (in)	10.6 in
Pulley Material	Cast Iron
Pitch Diameter (3V)	10.55
Material	Cast Iron
Bore (Min) (in)	0.75 in
Belt Section	3V
Product Type	Multiple Sheaves
Bore Type	Split Taper Bushed
Overall Width (in)	2.859375
Bushing Bore Range	2.6875 - 2.6875
Keyway Size	.500
Face Width (in)	1.9063
Pulley Construction	Spoked

General Specifications

UPC	662289200146
Weight	16.30 LB
Packaged Length	10.50 IN
Packaged Width	10.50 IN
Packaged Height	2.25 IN
