• Large Selection - MVP companion sheaves are offered in A/B, C, 5Vand 8V belt sections and from 3-10 grooves giving Browning the largest selection of MVP Companion Sheaves in the industry.
• Statically Balanced - All MVP companion sheaves are statically balanced to assure smooth, vibration free performance.
• VP sheaves consist of a male with a threaded barrel, and a female with a threaded bore.
• The male section with threaded barrel has flat surfaces at 180 degree increments that allow a flat surface for the setscrew to mate with.
• When discs are moved toward each other, the belt rides higher in the groove and the pitch diameter of the sheave is larger which increases the driven speed.
• When discs are moved away from each other, the belt rides lower and the pitch diameter is smaller decreasing the driven speed.

Technical Specifications

Type of Bore	Bushed
Bore (Min) (in)	1.375 in
Pitch Diameter Range (C)	11.1 - 8.9
Face Width (Max) (in)	6.6875 in
Product Type	MVP Sheaves
Face Width (Min) (in)	6.09375 in
Outside Diameter (in)	11.06 in
Material	Cast Iron
Number of Grooves	4
Ring	6.5
Outside Length (in)	7.9375 in
Belt Section	C
Bore (Max) (in)	2.5 in
Bore Type	Split Taper Bushed
Keyway Size	.500
Bushing Bore Range	1.375 - 2.500

General Specifications

UPC	662289105007
Weight	91.00 LB
Packaged Length	11.06 IN
Packaged Width	11.06 IN
Packaged Height	7.94 IN
HTC	8483.50.9040
Country of Origin	United States of America
