• Large Selection - MVP companion sheaves are offered in A/B, C, 5Vand 8V belt sections and from 3-10 grooves giving Browning the largest selection of MVP Companion Sheaves in the industry.
• Statically Balanced - All MVP companion sheaves are statically balanced to assure smooth, vibration free performance.
• VP sheaves consist of a male with a threaded barrel, and a female with a threaded bore.
• The male section with threaded barrel has flat surfaces at 180 degree increments that allow a flat surface for the setscrew to mate with.
• When discs are moved toward each other, the belt rides higher in the groove and the pitch diameter of the sheave is larger which increases the driven speed.
• When discs are moved away from each other, the belt rides lower and the pitch diameter is smaller decreasing the driven speed.

Technical Specifications

Outside Diameter (in)	9.75 in
Material	Cast Iron
Pitch Diameter Range (A)	9.2
Pitch Diameter Range (B)	9.7
Outside Length (in)	4.640625 in
Type of Bore	Bushed
Bore (Min) (in)	1 in
Number of Grooves	4
Product Type	MVP Sheaves
Belt Section	A, B
Bore Type	Split Taper Bushed
Pulley Construction	Webbed
Bore (Max) (in)	2.625 in
Face Width (in)	4.375 in
Bushing Used	Q2
Bushing Bore Range	1.000 - 2.625
Keyway Size	.500

General Specifications

UPC	662289115754
Weight	36.79 LB
Packaged Length	10.40 IN
Packaged Width	10.30 IN
Packaged Height	4.70 IN
HTC	8483.50.9040
Country of Origin	Mexico
