• Large Selection - MVP companion sheaves are offered in A/B, C, 5Vand 8V belt sections and from 3-10 grooves giving Browning the largest selection of MVP Companion Sheaves in the industry.
• Statically Balanced - All MVP companion sheaves are statically balanced to assure smooth, vibration free performance.
• VP sheaves consist of a male with a threaded barrel, and a female with a threaded bore.
• The male section with threaded barrel has flat surfaces at 180 degree increments that allow a flat surface for the setscrew to mate with.
• When discs are moved toward each other, the belt rides higher in the groove and the pitch diameter of the sheave is larger which increases the driven speed.
• When discs are moved away from each other, the belt rides lower and the pitch diameter is smaller decreasing the driven speed.

Technical Specifications

Pitch Diameter Range (A)	13.4
Bore (Min) (in)	1.125 in
Product Type	MVP Sheaves
Type of Bore	Bushed
Number of Grooves	4
Outside Diameter (in)	13.95 in
Pitch Diameter Range (B)	13.9
Material	Cast Iron
Outside Length (in)	4.359375 in
Belt Section	A, B
Bore Type	Split Taper Bushed
Pulley Construction	Spoked
Face Width (in)	4.375 in
Bushing Used	R1
Bore (Max) (in)	3.75 in
Keyway Size	.750
Bushing Bore Range	1.125 - 3.750

General Specifications

UPC	662289313013
Weight	48.97 LB
Packaged Length	14.40 IN
Packaged Width	14.60 IN
Packaged Height	4.90 IN
