• Wrapped construction - Browning offers a full line of wrapped FHP Belts which provides smooth quiet operation. Wrapped FHP Belts are more tolerant to slipping and misalignment than Raw Edge Belts.
• The best features of notched and wrapped belts. Designed for small sheave applications - Browning FHP Belts are formulated for maximum flexibility for use in small diameter sheaves.

Technical Specifications

Pitch Length	81
Belt Section	4L
Reinforcing cord material	Polyester
Color	Black
Material	Rubber
Standards met	ARPM IP-23
Section Size	4L
Construction Type	Wrapped
Belt Series	FHP Belts
Outside Length/Diameter (in)	82 in
Overall Width (in)	0.5 in
Operating Temperature [Max] ºF	140 °F
Product Type	FHP Belt
Cross Section	0.5
Operating Temperature [Max] ºC	60 °C
Width (in)	0.5 in
Resistance Features	Oil & Chemical per ARPM IP-3-2, Static Dissipating per ARPM IP-3-3
Operating Temperature Range	-32 to +140 °F
Part Height	.312

General Specifications

UPC	662289186143
Weight	0.49 LB
Packaged Length	5.45 IN
Packaged Width	12.00 IN
Packaged Height	1.75 IN
HTC	4010.34.3000
Country of Origin	Mexico
