• Wrapped construction - Browning offers a full line of wrapped FHP Belts which provides smooth quiet operation. Wrapped FHP Belts are more tolerant to slipping and misalignment than Raw Edge Belts.
• The best features of notched and wrapped belts. Designed for small sheave applications - Browning FHP Belts are formulated for maximum flexibility for use in small diameter sheaves.

Technical Specifications

Pitch Length	67
Belt Section	4L
Material	Rubber
Standards met	ARPM IP-23
Construction Type	Wrapped
Belt Series	FHP Belts
Section Size	4L
Reinforcing cord material	Polyester
Color	Black
Operating Temperature [Max] ºF	140 °F
Product Type	FHP Belt
Outside Length/Diameter (in)	68 in
Overall Width (in)	0.5 in
Operating Temperature [Max] ºC	60 °C
Cross Section	0.5
Width (in)	0.5 in
Resistance Features	Oil & Chemical per ARPM IP-3-2, Static Dissipating per ARPM IP-3-3
Operating Temperature Range	-32 to +140 °F
Part Height	.312

General Specifications

UPC	662289225934
Weight	0.40 LB
Packaged Length	6.05 IN
Packaged Width	9.35 IN
Packaged Height	1.45 IN
HTC	4010.32.3000
Country of Origin	Mexico
