• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Material	Cast Iron
Outside Diameter (in)	9.4 in
Number of Grooves	4
Bushing Used	R1
Pulley Material	Cast Iron
Pitch Diameter (C)	9.4
Overall Length (in)	4.296875 in
Datum Diameter (C)	9
Product Type	Multiple Sheaves
Bore (Min) (in)	1.125 in
Belt Section	C
Bore Type	Split Taper Bushed
Overall Width (in)	4.28125
Keyway Size	.750
Bushing Bore Range	1.125 - 3.750
Pulley Construction	Webbed
Face Width (in)	4.25

General Specifications

UPC	662289195855
Weight	32.19 LB
Packaged Length	10.90 IN
Packaged Width	9.90 IN
Packaged Height	4.70 IN
