• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Number of Grooves	4
Bushing Used	R1
Pitch Diameter (C)	18.4
Pulley Material	Cast Iron
Material	Cast Iron
Outside Diameter (in)	18.4 in
Overall Length (in)	4.296875 in
Datum Diameter (C)	18
Belt Section	C
Product Type	Multiple Sheaves
Bore (Min) (in)	1.125 in
Bore Type	Split Taper Bushed
Bushing Bore Range	1.125 - 3.750
Pulley Construction	Spoked
Keyway Size	.750
Overall Width (in)	4.28125
Face Width (in)	4.25

General Specifications

UPC	662289116904
Weight	67.58 LB
Packaged Length	18.75 IN
Packaged Width	18.75 IN
Packaged Height	4.25 IN
HTC	8483.50.9040
Country of Origin	Mexico
