• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Datum Diameter (C)	14
Bushing Used	R1
Number of Grooves	4
Material	Cast Iron
Pitch Diameter (C)	14.4
Overall Length (in)	4.296875 in
Outside Diameter (in)	14.4 in
Pulley Material	Cast Iron
Belt Section	C
Product Type	Multiple Sheaves
Bore (Min) (in)	1.125 in
Bore Type	Split Taper Bushed
Face Width (in)	4.25
Pulley Construction	Spoked
Keyway Size	.750
Overall Width (in)	4.28125
Bushing Bore Range	1.125 - 3.750

General Specifications

UPC	662289266661
Weight	46.35 LB
Packaged Length	15.75 IN
Packaged Width	15.75 IN
Packaged Height	4.25 IN
HTC	8483.50.9040
Country of Origin	Mexico
