• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Overall Length (in)	4.296875 in
Bushing Used	R1
Material	Cast Iron
Outside Diameter (in)	11.4 in
Pitch Diameter (C)	11.4
Number of Grooves	4
Pulley Material	Cast Iron
Datum Diameter (C)	11
Bore (Min) (in)	1.125 in
Product Type	Multiple Sheaves
Belt Section	C
Bore Type	Split Taper Bushed
Bushing Bore Range	1.125 - 3.750
Keyway Size	.750
Overall Width (in)	4.28125
Face Width (in)	4.25
Pulley Construction	Webbed

General Specifications

UPC	662289226405
Weight	33.78 LB
Packaged Length	11.88 IN
Packaged Width	11.88 IN
Packaged Height	4.25 IN
