• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Material	Cast Iron
Outside Diameter (in)	9.68 in
Bushing Used	SK
Datum Diameter (A)	9
Pitch Diameter (B)	9.7
Pulley Material	Cast Iron
Model Name	4AB_LG_Sheavemaster
Datum Diameter (B)	9.4
Pitch Diameter (A)	9.2
Number of Grooves	4
Product Type	Multiple Sheaves
Belt Section	A, B
Bore (Min) (in)	0.5 in
Bore Type	QD Bushed
Overall Width (in)	3.25
Bushing Bore Range	0.500 - 2.625
Pulley Construction	Spoked
Face Width (in)	3.25

General Specifications

UPC	662289403394
Weight	18.96 LB
Packaged Length	10.40 IN
Packaged Width	10.20 IN
Packaged Height	3.50 IN
