• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Pulley Material	Cast Iron
Model Name	4AB_LG_Sheavemaster
Bushing Used	SD
Datum Diameter (A)	6
Number of Grooves	4
Pitch Diameter (A)	6.2
Material	Cast Iron
Pitch Diameter (B)	6.7
Datum Diameter (B)	6.4
Outside Diameter (in)	6.75 in
Bore (Min) (in)	0.5 in
Belt Section	A, B
Product Type	Multiple Sheaves
Bore Type	QD Bushed
Pulley Construction	Plain
Face Width (in)	3.25
Overall Width (in)	3.25
Bushing Bore Range	0.500 - 2.000
Length Through Bore (in)	1.8125 in

General Specifications

UPC	662289363322
Weight	13.95 LB
Packaged Length	7.90 IN
Packaged Width	7.90 IN
Packaged Height	3.60 IN
