• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Outside Diameter (in)	6.55 in
Bushing Used	Q1
Number of Grooves	4
Material	Cast Iron
Pitch Diameter (A)	6
Datum Diameter (B)	6.2
Pitch Diameter (B)	6.5
Overall Length (in)	3.578125 in
Datum Diameter (A)	5.8
Pulley Material	Cast Iron
Product Type	Multiple Sheaves
Bore (Min) (in)	0.75 in
Belt Section	A, B
Bore Type	Split Taper Bushed
Face Width (in)	3.25
Overall Width (in)	3.53125
Bushing Bore Range	2.6875 - 2.6875
Keyway Size	.500
Pulley Construction	Webbed

General Specifications

UPC	662289144549
Weight	13.57 LB
Packaged Length	7.90 IN
Packaged Width	7.90 IN
Packaged Height	3.50 IN
