• Combination Groove - All Browning B5V Sheaves permit the running of A, 4L, B, 5L and 5V Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Broad horsepower coverage - The B5V is available in 1 through 6 grooves allowing it to cover from 5 to 125 horsepower drives
• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• New Casting design - The B5V castings were developed using CAD and Finite Elements Analysis to determine where to add and eliminate material.

Technical Specifications

Bushing Used	B
Model Name	4B5V-SheaveMaster
Pulley Material	Cast Iron
Material	Cast Iron
Number of Grooves	4
Outside Diameter (in)	5.48 in
Pitch Diameter (5V)	5.3
Pitch Diameter (B)	5.5
Datum Diameter (B)	5.2
Datum Diameter (A)	4.8
Overall Length (in)	4.21875 in
Pitch Diameter (A)	5
Product Type	Multiple Sheaves
Bore (Min) (in)	0.5 in
Belt Section	A, B, 5V
Bore Type	Split Taper Bushed
Number of Hubs	1
Pulley Construction	Solid
Bushing Bore Range	.500 - 2.4375
Face Width (in)	3.16
Overall Width (in)	4.24
Keyway Size	0.5

General Specifications

UPC	662289037377
Weight	7.74 LB
Packaged Length	6.40 IN
Packaged Width	6.60 IN
Packaged Height	3.40 IN
