• Combination Groove - All Browning B5V Sheaves permit the running of A, 4L, B, 5L and 5V Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Broad horsepower coverage - The B5V is available in 1 through 6 grooves allowing it to cover from 5 to 125 horsepower drives
• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• New Casting design - The B5V castings were developed using CAD and Finite Elements Analysis to determine where to add and eliminate material.

Technical Specifications

Pitch Diameter (B)	5.1
Material	Cast Iron
Number of Grooves	4
Outside Diameter (in)	5.08 in
Overall Length (in)	4.21875 in
Bushing Used	B
Pitch Diameter (5V)	4.9
Pulley Material	Cast Iron
Datum Diameter (B)	4.8
Datum Diameter (A)	4.4
Pitch Diameter (A)	4.6
Model Name	4B5V-SheaveMaster
Product Type	Multiple Sheaves
Bore (Min) (in)	0.5 in
Belt Section	A, B, 5V
Bore Type	Split Taper Bushed
Pulley Construction	Plain
Overall Width (in)	4.15625
Keyway Size	.500
Bushing Bore Range	0.500 - 2.4375
Face Width (in)	3.1563

General Specifications

UPC	662289037353
Weight	7.65 LB
Packaged Length	6.40 IN
Packaged Width	6.60 IN
Packaged Height	3.30 IN
