• Combination Groove - All Browning B5V Sheaves permit the running of A, 4L, B, 5L and 5V Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Broad horsepower coverage - The B5V is available in 1 through 6 grooves allowing it to cover from 5 to 125 horsepower drives
• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• New Casting design - The B5V castings were developed using CAD and Finite Elements Analysis to determine where to add and eliminate material.

Technical Specifications

Pitch Diameter (B)	4.5
Overall Length (in)	3.984375 in
Datum Diameter (A)	3.8
Pitch Diameter (A)	4
Material	Cast Iron
Pulley Material	Cast Iron
Datum Diameter (B)	4.2
Model Name	4B5V-SheaveMaster
Bushing Used	P1
Number of Grooves	4
Outside Diameter (in)	4.48 in
Pitch Diameter (5V)	4.3
Product Type	Multiple Sheaves
Belt Section	A, B, 5V
Bore (Min) (in)	0.5 in
Bore Type	Split Taper Bushed
Keyway Size	.375
Face Width (in)	3.1563
Overall Width (in)	4.03125
Bushing Bore Range	0.500 - 1.750
Pulley Construction	Plain

General Specifications

UPC	662289037827
Weight	6.45 LB
Packaged Length	5.00 IN
Packaged Width	5.00 IN
Packaged Height	3.90 IN
