• Combination Groove - All Browning B5V Sheaves permit the running of A, 4L, B, 5L and 5V Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Broad horsepower coverage - The B5V is available in 1 through 6 grooves allowing it to cover from 5 to 125 horsepower drives
• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• New Casting design - The B5V castings were developed using CAD and Finite Elements Analysis to determine where to add and eliminate material.

Technical Specifications

Pitch Diameter (5V)	13.7
Model Name	4B5V-SheaveMaster
Pitch Diameter (A)	13.4
Material	Cast Iron
Pulley Material	Cast Iron
Outside Diameter (in)	13.88 in
Overall Length (in)	3.265625 in
Bushing Used	B
Datum Diameter (A)	13.2
Pitch Diameter (B)	13.9
Number of Grooves	4
Datum Diameter (B)	13.6
Belt Section	A, B, 5V
Bore (Min) (in)	0.5 in
Product Type	Multiple Sheaves
Number of Hubs	1
Bore Type	Split Taper Bushed
Overall Width (in)	3.28
Pulley Construction	Spoke
Keyway Size	0.5
Bushing Bore Range	.500 - 2.4375
Face Width (in)	3.16

General Specifications

UPC	662289035335
Weight	35.34 LB
Packaged Length	14.40 IN
Packaged Width	14.60 IN
Packaged Height	3.40 IN
