• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Bushing Used	SD
Pitch Diameter (B)	4.9
Pitch Diameter (A)	4.4
Material	Cast Iron
Datum Diameter (A)	4.2
Datum Diameter (B)	4.6
Pulley Material	Cast Iron
Number of Grooves	4
Model Name	4AB_LG_Sheavemaster
Outside Diameter (in)	4.95 in
Product Type	Multiple Sheaves
Belt Section	A, B
Bore (Min) (in)	0.5 in
Bore Type	QD Bushed
Bushing Bore Range	0.500 - 2.000

General Specifications

UPC	662289363254
Weight	6.65 LB
Packaged Length	5.50 IN
Packaged Width	5.50 IN
Packaged Height	3.50 IN
