• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Number of Grooves	4
Model Name	4AB_LG_Sheavemaster
Material	Cast Iron
Outside Diameter (in)	4.15 in
Bushing Used	SD
Pulley Material	Cast Iron
Pitch Diameter (B)	4.1
Pitch Diameter (A)	3.6
Datum Diameter (B)	3.8
Datum Diameter (A)	3.4
Product Type	Multiple Sheaves
Bore (Min) (in)	0.5 in
Belt Section	A, B
Bore Type	QD Bushed
Bushing Bore Range	0.500 - 2.000

General Specifications

UPC	662289403240
Weight	6.04 LB
Packaged Length	4.25 IN
Packaged Width	4.25 IN
Packaged Height	3.69 IN
HTC	8483.50.9040
Country of Origin	Mexico
