• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Pitch Diameter (A)	29.8
Material	Cast Iron
Datum Diameter (A)	29.6
Pulley Material	Cast Iron
Outside Diameter (in)	30.35 in
Bushing Used	E
Number of Grooves	4
Datum Diameter (B)	30
Model Name	4AB_LG_Sheavemaster
Pitch Diameter (B)	30.3
Belt Section	A, B
Product Type	Multiple Sheaves
Bore (Min) (in)	0.875 in
Bore Type	QD Bushed
Bushing Bore Range	0.875 - 3.500

General Specifications

UPC	662289387601
Weight	86.00 LB
Packaged Length	30.35 IN
Packaged Width	30.35 IN
Packaged Height	3.25 IN
HTC	8483.50.9040
Country of Origin	China
