• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Pulley Material	Cast Iron
Overall Length (in)	3.796875 in
Pitch Diameter (B)	20.3
Datum Diameter (A)	19.6
Bushing Used	R1
Number of Grooves	4
Pitch Diameter (A)	19.8
Material	Cast Iron
Outside Diameter (in)	20.35 in
Datum Diameter (B)	20
Product Type	Multiple Sheaves
Belt Section	A, B
Bore (Min) (in)	1.125 in
Bore Type	Split Taper Bushed
Keyway Size	.750
Pulley Construction	Spoked
Overall Width (in)	3.78125
Bushing Bore Range	1.125 - 3.750
Face Width (in)	3.25

General Specifications

UPC	662289275380
Weight	57.55 LB
Packaged Length	20.38 IN
Packaged Width	20.38 IN
Packaged Height	3.25 IN
