• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Material	Cast Iron
Overall Length (in)	3.796875 in
Bushing Used	R1
Datum Diameter (B)	16
Datum Diameter (A)	15.6
Outside Diameter (in)	16.35 in
Number of Grooves	4
Pulley Material	Cast Iron
Pitch Diameter (A)	15.8
Pitch Diameter (B)	16.3
Product Type	Multiple Sheaves
Bore (Min) (in)	1.125 in
Belt Section	A, B
Bore Type	Split Taper Bushed
Pulley Construction	Spoked
Bushing Bore Range	1.125 - 3.750
Face Width (in)	3.25
Overall Width (in)	3.78125
Keyway Size	.750

General Specifications

UPC	662289310999
Weight	47.10 LB
Packaged Length	17.30 IN
Packaged Width	17.20 IN
Packaged Height	3.40 IN
