• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Number of Grooves	4
Bushing Used	R1
Pulley Material	Cast Iron
Outside Diameter (in)	15.75 in
Material	Cast Iron
Datum Diameter (A)	15
Overall Length (in)	3.796875 in
Datum Diameter (B)	15.4
Pitch Diameter (A)	15.2
Pitch Diameter (B)	15.7
Bore (Min) (in)	1.125 in
Product Type	Multiple Sheaves
Belt Section	A, B
Bore Type	Split Taper Bushed
Bushing Bore Range	1.125 - 3.750
Face Width (in)	3.25
Overall Width (in)	3.78125
Keyway Size	.750
Pulley Construction	Spoked

General Specifications

UPC	662289310968
Weight	41.11 LB
Packaged Length	16.10 IN
Packaged Width	16.20 IN
Packaged Height	3.50 IN
