• Constant Speed - No slip; no creep; minimum backlash due to the positive engagement of the belt teeth with the grooves of the sprockets.
• Light Weight - High horsepower-to-weight ratio makes Browning Gearbelt drives ideal for any application where weight is a factor.
• Broad depth of product to choose from - Browning offers 5 different sprocket pitches along with a wide range of sprocket and belt widths to accommodate any horsepower requirement.
• Different Mounting to the shaft - Browning offers the Gearbelt Pulleys in various ways to mount to the shaft; Split Taper and QD Bushing styles, as well as, finished and minimum plain bore.

Technical Specifications

Model Name	GBPulley_Master1
Bore Range	5/16 to 1
Number of teeth	48
Width (mm)	9.525 mm
Product Type	Gearbelt Pulley
Material	Aluminium
Bore Type	Rough Bore
Outside Diameter (in)	2.781 in
Outside Diameter (mm)	77.1144 mm
Pitch Diameter (in)	2.801 in
Belt Section	XL
Width (in)	0.375 in
Face Width	0.5625
Number of Hubs	1
Length Through Bore	1
Hub Diameter (in)	1.5 in
Pulley Construction	Solid
With Flanges	No Flanges
Overall Length (in)	1 in
Hub Projection	0.4375
Bore Diameter (in)	0.3125 in

General Specifications

UPC	662289102136
Weight	0.92 LB
Packaged Length	3.20 IN
Packaged Width	3.20 IN
Packaged Height	1.50 IN
HTC	8483.50.9080
Country of Origin	United States of America
