• Constant Speed - No slip; no creep; minimum backlash due to the positive engagement of the belt teeth with the grooves of the sprockets.
• Light Weight - High horsepower-to-weight ratio makes Browning Gearbelt drives ideal for any application where weight is a factor.
• Broad depth of product to choose from - Browning offers 5 different sprocket pitches along with a wide range of sprocket and belt widths to accommodate any horsepower requirement.
• Different Mounting to the shaft - Browning offers the Gearbelt Pulleys in various ways to mount to the shaft; Split Taper and QD Bushing styles, as well as, finished and minimum plain bore.

Technical Specifications

Product Type	Gearbelt Pulley
Bore Range	1/2 to 1 3/4
Width (mm)	25.4 mm
Number of teeth	48
Bore Type	Bushed Bore
Material	Ductile Iron
Width (in)	1 in
Outside Diameter (in)	5.7 in
Flange (in)	5.950 in
Pitch Diameter (in)	5.73 in
Belt Section	L
Outside Diameter (mm)	144.78 mm
Face Width	1.25
Hub Diameter (in)	3 in
Pulley Construction	Solid
Hub Projection	0.875
Number of Hubs	1
With Flanges	With Flanges
Length Through Bore	1.938
Overall Length (in)	2.21925 in

General Specifications

UPC	662289233595
Weight	7.67 LB
Packaged Length	6.40 IN
Packaged Width	6.50 IN
Packaged Height	2.50 IN
HTC	8483.50.9080
Country of Origin	United States of America
