• Constant Speed - No slip; no creep; minimum backlash due to the positive engagement of the belt teeth with the grooves of the sprockets.
• Light Weight - High horsepower-to-weight ratio makes Browning Gearbelt drives ideal for any application where weight is a factor.
• Broad depth of product to choose from - Browning offers 5 different sprocket pitches along with a wide range of sprocket and belt widths to accommodate any horsepower requirement.
• Different Mounting to the shaft - Browning offers the Gearbelt Pulleys in various ways to mount to the shaft; Split Taper and QD Bushing styles, as well as, finished and minimum plain bore.

Technical Specifications

Product Type	Gearbelt Pulley
Number of teeth	48
Model Name	GBPulley_Master6
Width (mm)	19.05 mm
Bore Range	1/2 to 2
Material	Steel
Bore Type	Bushed Bore
Outside Diameter (mm)	144.78 mm
Outside Diameter (in)	5.7 in
Flange (in)	6.0000 in
Pitch Diameter (in)	5.73 in
Belt Section	L
Width (in)	0.75 in
Face Width	1
Number of Hubs	1
Overall Length (in)	1.6875 in
Hub Diameter (in)	2.1875 in
Hub Projection	0.6875
Length Through Bore	1.33
Pulley Construction	Solid
With Flanges	With Flanges

General Specifications

UPC	662289352715
Weight	4.69 LB
Packaged Length	6.30 IN
Packaged Width	6.40 IN
Packaged Height	2.50 IN
HTC	8483.50.9080
Country of Origin	United States of America
