• Constant Speed - No slip; no creep; minimum backlash due to the positive engagement of the belt teeth with the grooves of the sprockets.
• Light Weight - High horsepower-to-weight ratio makes Browning Gearbelt drives ideal for any application where weight is a factor.
• Broad depth of product to choose from - Browning offers 5 different sprocket pitches along with a wide range of sprocket and belt widths to accommodate any horsepower requirement.
• Different Mounting to the shaft - Browning offers the Gearbelt Pulleys in various ways to mount to the shaft; Split Taper and QD Bushing styles, as well as, finished and minimum plain bore.

Technical Specifications

Width (mm)	12.7 mm
Product Type	Gearbelt Pulley
Model Name	GBPulley_Master6
Bore Range	1/2 to 2
Number of teeth	48
Material	Steel
Bore Type	Bushed Bore
Belt Section	L
Outside Diameter (mm)	144.78 mm
Outside Diameter (in)	5.7 in
Pitch Diameter (in)	5.73 in
Width (in)	0.5 in
Flange (in)	6.0000 in
Face Width	0.75
Hub Diameter (in)	3.13 in
Length Through Bore	1.33
Hub Projection	0.95025
With Flanges	With Flanges
Overall Length (in)	1.70025 in
Pulley Construction	Solid
Number of Hubs	1

General Specifications

UPC	662289352647
Weight	4.23 LB
Packaged Length	6.30 IN
Packaged Width	6.20 IN
Packaged Height	2.30 IN
HTC	8483.50.9080
Country of Origin	United States of America
