• Constant Speed - No slip; no creep; minimum backlash due to the positive engagement of the belt teeth with the grooves of the sprockets.
• Light Weight - High horsepower-to-weight ratio makes Browning Gearbelt drives ideal for any application where weight is a factor.
• Broad depth of product to choose from - Browning offers 5 different sprocket pitches along with a wide range of sprocket and belt widths to accommodate any horsepower requirement.
• Different Mounting to the shaft - Browning offers the Gearbelt Pulleys in various ways to mount to the shaft; Split Taper and QD Bushing styles, as well as, finished and minimum plain bore.

Technical Specifications

Width (mm)	76.2 mm
Product Type	Gearbelt Pulley
Number of teeth	48
Bore Range	3/4 to 2 11/16
Material	Ductile Iron
Bore Type	Bushed Bore
Flange (in)	7.8670 in
Outside Diameter (mm)	192.659 mm
Belt Section	H
Width (in)	3 in
Pitch Diameter (in)	7.639 in
Outside Diameter (in)	7.585 in
Inside Diameter (in)	6.375 in
Face Width	3.3125
Pulley Construction	Solid
Length Through Bore	2.5
Overall Length (in)	3.59375 in
With Flanges	With Flanges

General Specifications

UPC	662289274284
Weight	22.12 LB
Packaged Length	7.88 IN
Packaged Width	7.88 IN
Packaged Height	3.25 IN
HTC	8483.50.9080
Country of Origin	United States of America
