• Constant Speed - No slip; no creep; minimum backlash due to the positive engagement of the belt teeth with the grooves of the sprockets.
• Light Weight - High horsepower-to-weight ratio makes Browning Gearbelt drives ideal for any application where weight is a factor.
• Broad depth of product to choose from - Browning offers 5 different sprocket pitches along with a wide range of sprocket and belt widths to accommodate any horsepower requirement.
• Different Mounting to the shaft - Browning offers the Gearbelt Pulleys in various ways to mount to the shaft; Split Taper and QD Bushing styles, as well as, finished and minimum plain bore.

Technical Specifications

Number of teeth	48
Product Type	Gearbelt Pulley
Bore Range	3/4 to 2 11/16
Width (mm)	50.8 mm
Model Name	GBPulley_Master5
Bore Type	Bushed Bore
Material	Ductile Iron
Inside Diameter (in)	6.375 in
Pitch Diameter (in)	7.639 in
Outside Diameter (in)	7.585 in
Outside Diameter (mm)	192.659 mm
Flange (in)	7.867 in
Belt Section	H
Width (in)	2 in
Face Width	2.34375
Pulley Construction	Solid
With Flanges	With Flanges
Length Through Bore	2.5
Overall Length (in)	2.78125 in
Number of Hubs	1
Hub Diameter (in)	4.125 in
Hub Projection	0.40625

General Specifications

UPC	662289174133
Weight	19.18 LB
Packaged Length	8.30 IN
Packaged Width	8.20 IN
Packaged Height	2.90 IN
HTC	8483.50.9080
Country of Origin	United States of America
