• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Outside Diameter (in)	13.2 in
Pitch Diameter (5V)	13.1
Number of Grooves	4
Material	Cast Iron
Bushing Used	E
Pulley Material	Cast Iron
Model Name	45V_LG_Sheavemaster
Bore (Min) (in)	0.875 in
Product Type	Multiple Sheaves
Belt Section	5V
Bore Type	QD Bushed
Bushing Bore Range	0.875 - 3.500
Face Width (in)	3.0625
Overall Width (in)	3.03125
Pulley Construction	Spoked
Length Through Bore (in)	2.75 in

General Specifications

UPC	662289393619
Weight	37.72 LB
Packaged Length	14.40 IN
Packaged Width	14.60 IN
Packaged Height	3.30 IN
